The vector A has a magnitude of 16.5 and a direction of 146 degrees. The vector...

The vector A has a magnitude of 16.5 and a direction of 146 degrees. The vector B has a magnitude of 17 and a direction of 69.5 degrees. The vector C has a magnitude of 16.5 and a direction of 32 degrees. All angles are measured counterclockwise from the positive x axis. The vector D follows the following relation: D = A + B − C What are the magnitude and direction of the vector D?

Solutions

Expert Solution

Colby Messinger answered 1 year ago
