Question

In: Computer Science

The below mentioned figure shows a General diagnosis flowchart for troubleshooting HP servers. Use the flowchart...

The below mentioned figure shows a General diagnosis flowchart for troubleshooting HP servers. Use
the flowchart to create a C++ program that leads a person through the steps of fixing a bad HP server.
Here is an example of the program’s output (following one of the flow):
Starting General Diagnosis Program.
Recoding symptoms information - DONE.
Rebooting server to see if condition still exists - DONE.
Is this a newly installed server? yes [enter]
Please reseat any components that may have come loose during shipping - DONE.
Rebooting the server - DONE.
Does the condition still exist? no [enter]
Recording all actions taken for future - DONE.
Congratulations, your server problems are solved.
Notice the program ends as soon as a solution is found to the problem.

Solutions

Expert Solution

CODE:

#include<iostream>
#include<iomanip>
#include<cstring>
#include<bits/stdc++.h>
using namespace std;

int main() {
   cout<<"Starting General Diagnosis Program";
       string ans;
   cout<<"\nRecording symptoms information - DONE"; // (1)
   cout<<"\nRebooting server to see if condition still exists - DONE";
   cout<<"\nIs this a newly installed server?";
   cin>>ans; transform(ans.begin(), ans.end(), ans.begin(), ::tolower);
   if(strcmp(ans.c_str(),"yes")==0) { //(2)
       cout<<"\nPlease reseat any components that may have come loose during shipping - DONE";
       cout<<"\nRebooting the server. - DONE";
       cout<<"\nDoes condition still exist? ";
       cin>>ans; transform(ans.begin(), ans.end(), ans.begin(), ::tolower);
       if (strcmp(ans.c_str(),"yes")==0) {
           goto checkConfigChange;
       }
       else {
           goto recordAllActions;
       }
   }
   else {
   checkConfigChange:
       cout<<"\nWere options added or was the configuration changed recently: ";
       cin>>ans; transform(ans.begin(), ans.end(), ans.begin(), ::tolower);
       if (strcmp(ans.c_str(),"yes")==0) {

           cout<<"\nIsolating what has changed - DONE \n Verifying it was installed correctly - DONE.\n Restoring server to last known working state or original shipped configuration - DONE";

           cout<<"\nDoes condition still exist? ";
           cin>>ans; transform(ans.begin(), ans.end(), ans.begin(), ::tolower);
           if (strcmp(ans.c_str(),"yes")==0) {

               IsolateMinMemConfig: //(5)
               cout<<"\nIsolating and minimizing the memory configuration - DONE";

               cout<<"\nDoes condition still exist? ";
               cin>>ans; transform(ans.begin(), ans.end(), ans.begin(), ::tolower);
               if (strcmp(ans.c_str(),"yes")==0) {
                   cout<<"\nBreaking server down to minimal configuration. - DONE";
                   cout<<"\nDoes condition still exist? ";
                   cin>>ans; transform(ans.begin(), ans.end(), ans.begin(), ::tolower);
                   if (strcmp(ans.c_str(),"yes")==0) { //(7)
                       cout<<"\nTroubleshoot or replace basic server spare parts - DONE";

                       cout<<"\nDoes condition still exist? ";
                       cin>>ans; transform(ans.begin(), ans.end(), ans.begin(), ::tolower);
                       if (strcmp(ans.c_str(),"yes")==0) {
                           //( 8 )
                           CollectSystemInfo:
                           cout<<"\n Ensuring whether following information is available: \n 1. Survey configuration snapshots \n \
                           2. OS event log file \n \
                           3. Full crash dump. - DONE";

                       }
                       else {
                           cout<<"\n Recording symptom and error information on repair tag if sending back a failed part - DONE";
                           goto end;
                       }

                   }
                   else { //(6)
                       cout<<"Adding all parts, one part at a time back to configuration to isolate faulty component . -DONE";
                       cout<<"\nDoes condition still exist? ";
                       cin>>ans; transform(ans.begin(), ans.end(), ans.begin(), ::tolower);
                       if (strcmp(ans.c_str(),"yes")==0) {
                           goto CollectSystemInfo;
                       }
                       else { goto recordAllActions;}
                   }

               }
               else { goto recordAllActions;}

           }
           else { goto recordAllActions;}
       }
       else {
           cout<<"\nChecking for Service Notification - DONE"; //(3)
           cout<<"\nDownloading the latest software and firmware from the HP website - DONE"; //(4)

           cout<<"\nDoes condition still exist? ";
           cin>>ans; transform(ans.begin(), ans.end(), ans.begin(), ::tolower);
           if (strcmp(ans.c_str(),"yes")==0) {
               goto IsolateMinMemConfig;
           }
           else { goto recordAllActions;}

       }
   }

   recordAllActions:
   cout<<"\nRecording all actions taken for future - DONE.";

   end:
   cout<<"\nCongratulations, your server problems are solved";
   return 0;

   callHP:
   cout<<"\nPlease Call HP Service Provider."; //(9)
   return 0;
}

Snapshot:

case 1:

Case 2:
