Question

There are a lot of networking and network security jobs and every IT company has network engineers, admins, etc. Why and how do think understanding the OSI Model and Network Devices are important from a work standpoint? Looking for some original content.

Answer 1

OSI

OSI (Open Systems Interconnection) is a reference model for how applications communicate over a network.

A reference model is a conceptual framework for understanding relationships. The purpose of the OSI reference model is to guide vendors and developers so the digital communication products and software programs they create can interoperate, and to facilitate a clear framework that describes the functions of a networking or telecommunication system.

Most vendors involved in telecommunications make an attempt to describe their products and services in relation to the OSI model. And although it is useful for guiding discussion and evaluation, OSI is rarely actually implemented as-is. That's because few network products or standard tools keep related functions together in well-defined layers, as is the case in the OSI model. The TCP/IP protocol suite, which defines the internet, does not map cleanly to the OSI model

How the OSI model works

IT professionals use OSI to model or trace how data is sent or received over a network. This model breaks down data transmission over a series of seven layers, each of which is responsible for performing specific tasks concerning sending and receiving data.

The main concept of OSI is that the process of communication between two endpoints in a network can be divided into seven distinct groups of related functions, or layers. Each communicating user or program is on a device that can provide those seven layers of function.

In this architecture, each layer serves the layer above it and, in turn, is served by the layer below it. So, in a given message between users, there will be a flow of data down through the layers in the source computer, across the network, and then up through the layers in the receiving computer. Only the application layer, at the top of the stack, doesn’t provide services to a higher-level layer.

The seven layers of function are provided by a combination of applications, operating systems, network card device drivers and networking hardware that enable a system to transmit a signal over a network Ethernet or fiber optic cable or through Wi-Fi or other wireless protocols.

When most non-technical people hear the term “seven layers”, they either think of the popular Super Bowl bean dip or they mistakenly think about the seven layers of Hell, courtesy of Dante’s Inferno (there are nine). For IT professionals, the seven layers refer to the Open Systems Interconnection (OSI) model, a conceptual framework that describes the functions of a networking or telecommunication system.

The model uses layers to help give a visual description of what is going on with a particular networking system. This can help network managers narrow down problems (Is it a physical issue or something with the application?), as well as computer programmers (when developing an application, which other layers does it need to work with?). Tech vendors selling new products will often refer to the OSI model to help customers understand which layer their products work with or whether it works “across the stack”.
