Question
In: Mechanical Engineering
The flow rate of warm air into the air conditioning is 5,000 cfm. An air conditioning...
The flow rate of warm air into the air conditioning is 5,000 cfm. An air conditioning system takes outdoor air at 95 degrees F dry-bulb and 70% relative humidity, and discharges it at 60 degrees F dry-bulb and 95% relative humidity. The air conditioning system operates on a vapor compression cycle using R134a between 20 and 200 psia. Refrigerant enters the compressor at 20 degrees F and leaves the compressor at 180 degrees F. Refrigerant enters the evaporator coil at a quality of x = 0.3. Determine a) The quantity of water removed from the air, in lb/min. b) The quantity of heat removed from the air, in tons. c) The mass flow rate of refrigerant, in lb/s. d) The compressor's power requirement, in hp.
Solutions
samet mamat answered 2 years agoRelated Solutions
