Question

In: Physics

A ballistic with mass of m=5.38-Oz was fired towards a Ballistic Pendulum at initial velocity of...

A ballistic with mass of m=5.38-Oz was fired towards a Ballistic Pendulum at initial velocity of υ into a large block of wood with mass of M=20.31_kg. As a result of the collision the pendulum and the projectile together swung up to the maximum height h = 0.831_m at a velocity of υb. Find a) υb velocity soon after impact, b) initial velocity υa , c) KE of the small mass, d) KE of the combined mass, e) PE of combined mass at hmax. 1_Oz = 0.0283495_kg.

Solutions

Expert Solution


Related Solutions

A cannonball is fired towards a cliff with an initial velocity of 300 m/s at an...
A cannonball is fired towards a cliff with an initial velocity of 300 m/s at an angle of 55º above the horizontal. It explodes 42 seconds later. If we assume that our reference (0,0) is the cannon that fired it, calculate the coordinates (x, y) at which the cannon hits the cliff. Hint: Calculate the range of the projectile in 42 seconds and the height it has in that time
A bullet of mass m is fired from the initial ground velocity of magnitude v0 at...
A bullet of mass m is fired from the initial ground velocity of magnitude v0 at elevation angle θ0. (a) Express her momentum relative to the location of the shot as a function of time. (b) How fast does the momentum change? (c) Calculate the size vector r × F directly and compare it with the result of problem (b). Why both results are identical
A ballistic pendulum consists of a large heavy mass, M on the end of a very...
A ballistic pendulum consists of a large heavy mass, M on the end of a very light rod of length L. The rod is free to pivot at the top and the mass is attached at the bottom, so it hangs like a pendulum. A second mass, m, is fired horizontally at speed v straight into the large mass, and they stick together. The pendulum swings to a maximum angle ?m. a)Show that you can measure v by measuring ?m,...
A ballistic pendulum consists of a thin rod AB (length = 2.0 m; mass = 1.14...
A ballistic pendulum consists of a thin rod AB (length = 2.0 m; mass = 1.14 kg) that is rigidly attached to a solid sphere that has a center C, radius = 0.4 m, and mass = 2.45 kg. A bullet (mass = 0.01 kg) is fired at point C with a speed of 675 m/s. Determine the amount of kinetic energy lost by the system due to the impact.
A spring gun fires a bullet of mass m=.04 kg horizontally at a ballistic pendulum apparatus...
A spring gun fires a bullet of mass m=.04 kg horizontally at a ballistic pendulum apparatus with a mass M=.350. the bullet lodges itself into the pendulum. After collision, the center of mass of the bullet and pendulum rises by .07 meters. What is the approximate initial speed v of the bullet?
Fill the spaces 1. In the ballistic pendulum, if the ball mass is m1 = 10g...
Fill the spaces 1. In the ballistic pendulum, if the ball mass is m1 = 10g and the block mass is 8.0kg and the height you both reach is 5.0cm, the initial speed of the ball is________. 2. When the external net _________ on an object system is zero, the total amount of movement remains at ________. 3. The ________ of a force on an object is equal to the change in the momentum of the object so much that...
A bullet of mass 4.3 g strikes a ballistic pendulum of mass 1.9 kg. The center...
A bullet of mass 4.3 g strikes a ballistic pendulum of mass 1.9 kg. The center of mass of the pendulum rises a vertical distance of 12 cm. Assuming that the bullet remains embedded in the pendulum, calculate the bullet's initial speed.
A bullet of mass 2.7 g strikes a ballistic pendulum of mass 2.7 kg. The center...
A bullet of mass 2.7 g strikes a ballistic pendulum of mass 2.7 kg. The center of mass of the pendulum rises a vertical distance of 11 cm. Assuming that the bullet remains embedded in the pendulum, calculate the bullet's initial speed.
On level ground a shell is fired with an initial velocity of 36.0 m/s at 58.0...
On level ground a shell is fired with an initial velocity of 36.0 m/s at 58.0 ∘ above the horizontal and feels no appreciable air resistance. ((INCLUDE ALL ANSWER WITH THE UNITS LIKE m/s OR WHATEVER)) THANK YOU A) Find the horizontal and vertical components of the shell's initial velocity. B) How long does it take the shell to reach its highest point? C) Find its maximum height above the ground. D) How far from its firing point does the...
An artillery shell is fired with an initial velocity of 300 m/s at 52.0° above the...
An artillery shell is fired with an initial velocity of 300 m/s at 52.0° above the horizontal. To clear an avalanche, it explodes on a mountainside 47.5 s after firing. What are the x- and y-coordinates of the shell where it explodes, relative to its firing point? x = ________ m y = ________
