Only two forces act on an object (mass=4.27 kg), as in the drawing. Find (a) the...

Only two forces act on an object (mass=4.27 kg), as in the drawing. Find (a) the magnitude and (b) the direction (relative to the x axis) of the acceleration of the object. x= 40 N y= 60N with an angle of 45 degrees

Expert Solution

I hope you understood the problem and got your answers, If yes rate me!! or else comment for a better solutions

genius_generous answered 2 months ago
