Exercise 1.40 You are given two vectors A⃗ =−3.00ι^+6.00j^and B⃗ =4.00ι^+2.00j^. Let the counterclockwise angles be...

Exercise 1.40
You are given two vectors A⃗ =−3.00ι^+6.00j^and B⃗ =4.00ι^+2.00j^. Let the counterclockwise angles be positive.
Part A
What angle does A⃗ make with the +x-axis?

θ1=
∘

SubmitMy AnswersGive Up
Part B
What angle does B⃗ make with the +x-axis?

θ2=
∘

SubmitMy AnswersGive Up
Part C
Vector C⃗ is the sum of A⃗ and B⃗ , so C⃗ =A⃗ +B⃗ . What angle does C⃗ make with the +x-axis?

θ3=

Expert Solution
