Question

In C++ for netbeans.

Use a 1 dimensional array object to create a 2 dimensional table object. Then modify to create a triangular table.

Objective -> create an array of dynamic objects of RowAray inside Table i.e. an Aggregate. See Specs RowAray.h, Table.h Then create a triangular table, i.e. Triangle.

Fill each cell with random 2 digit integers. The example Table has 8 columns of RowAray objects each filled with 6 rows of random 2 digit numbers.

Then create a triangular table using the concept of the original table.

Complete the class implementations RowAray.cpp, Table,cpp, and Triangle.cpp use the driver program, obtain similar results.

https://github.com/ml1150258/2019_Fall_CSC-CIS_17c/tree/master/Hmwk/Review1_CSC17c_Object_Array

When complete for #rows=#cols, then create a version 2 that does a random number of cols per row with sorted column size output like the first assignment for the Triangular Matrix.

We will augment this assignment later and progress to templates.

Answer 1

If you have any doubts, please give me comment...

RowAray.h

/*

* File:   RowAray.h

* Author: Dr. Mark E. Lehr

* Created on January 22nd, 2019, 8:36 PM

* Specification for the RowAray

*/

#ifndef ROWARAY_H

#define ROWARAY_H

#include <cstdlib>

class RowAray

{

private:

    int size;

    int *rowData;

public:

    RowAray(int size);

    ~RowAray();

    int getSize();

    int getData(int i);

};

#endif

RowAray.cpp

#include "RowAray.h"

RowAray::RowAray(int size)

{

    this->size = size;

    rowData = new int[size];

    for (int i = 0; i < size; i++)

    {

        rowData[i] = (rand() % 90) + 10;

    }

}

RowAray::~RowAray()

{

    delete rowData;

}

int RowAray::getSize()

{

    return size;

}

int RowAray::getData(int i)

{

    return rowData[i];

}

Table.h

/*
 * File:   Table.h
 * Author: Dr. Mark E. Lehr
 * Created on January 22nd, 2019, 8:36 PM
 * Specification for the Table
 */

#ifndef TABLE_H

#define TABLE_H

#include "RowAray.h"

class Table

{

private:

    int szRow;

    int szCol;

    RowAray **records;

public:

    Table(int row, int col);

    ~Table();

    int getSzRow();

    int getSzCol();

    int getData(int r, int c);

};

#endif

Table.cpp

/*
 * File:   Triangle.h
 * Author: Dr. Mark E. Lehr
 * Created on January 22nd, 2019, 8:36 PM
 * Purpose:  Specification of a Triangular array from a Row Array
 */

#include "Table.h"

Table::Table(int row, int col)

{

    this->szRow = row;

    this->szCol = col;

    records = new RowAray *[row];

    for (int i = 0; i < row; i++)

        records[i] = new RowAray(col);

}

Table::~Table()

{

    delete[] records;

}

int Table::getSzRow()

{

    return szRow;

}

int Table::getSzCol()

{

    return szCol;

}

int Table::getData(int r, int c)

{

    return records[r]->getData(c);

}

Triangle.h

#ifndef TRIANGLE_H

#define TRIANGLE_H

#include "RowAray.h"

class Triangle

{

private:

    int szRow;

    RowAray **records;

public:

    Triangle(int row);

    ~Triangle();

    int getSzRow();

    int getData(int r, int c);

};

#endif

Triangle.cpp

#include "Triangle.h"

Triangle::Triangle(int row)

{

    this->szRow = row;

    records = new RowAray *[row];

    for (int i = 0; i < row; i++)

        records[i] = new RowAray(row);

}

Triangle::~Triangle()

{

    delete[] records;

}

int Triangle::getSzRow()

{

    return szRow;

}

int Triangle::getData(int r, int c)

{

    return records[r]->getData(c);

}

main.cpp

/*

* File:   main.cpp

* Author: Dr. Mark E. Lehr

* Created on January 22nd, 2019, 8:36 PM

* Purpose:  Dynamic Object Arrays

*/

//User Libraries

#include <cstdlib>

#include <ctime>

#include <iostream>

using namespace std;

//User Libraries

#include "Table.h"

#include "Triangle.h"

//Global Constants

//Function Prototype

void prntRow(RowAray *, int);

void prntTab(Table *);

void prntTri(Triangle *);

//Execution Begins Here!

int main(int argc, char **argv)

{

    //Initialize the random seed

    srand(static_cast<unsigned int>(time(0)));

    //Declare Variables

    int rows = 6, cols = 8, perLine = cols / 2;

    //Test out the RowAray

    RowAray row(cols);

    //Print the RowAray

    cout << "The Row Array size = " << row.getSize()

         << " printed " << perLine << " per Line";

    prntRow(&row, perLine);

    //Test out the Table

    Table tab(rows, cols);

    //Print the Table

    cout << "The table size is [row,col] = [" << rows << "," << cols << "]";

    prntTab(&tab);

    //Test out the Triangular Table

    Triangle tri(rows);

    //Print the Triangular Table

    cout << "The triangular table size is [row,row] = [" << rows << "," << rows << "]";

    prntTri(&tri);

    //Exit Stage Right

    return 0;

}

void prntRow(RowAray *a, int perLine)

{

    cout << endl;

    for (int i = 0; i < a->getSize(); i++)

    {

        cout << a->getData(i) << " ";

        if (i % perLine == (perLine - 1))

            cout << endl;

    }

    cout << endl;

}

void prntTab(Table *a)

{

    cout << endl;

    for (int row = 0; row < a->getSzRow(); row++)

    {

        for (int col = 0; col < a->getSzCol(); col++)

        {

            cout << a->getData(row, col) << " ";

        }

        cout << endl;

    }

    cout << endl;

}

void prntTri(Triangle *a)

{

    cout << endl;

    for (int row = 0; row < a->getSzRow(); row++)

    {

        for (int col = 0; col <= row; col++)

        {

            cout << a->getData(row, col) << " ";

        }

        cout << endl;

    }

    cout << endl;

}
